KUKA KSS01005 Software Option Missing – Causes, Diagnostics & How to Fix

Error Code Overview

• Error Code: KSS01005
• Category: Software Configuration / Licensing / Tech Packages
• Severity: Medium
• System: KRC Controller / WorkVisual / KSS (KUKA System Software)
• Impact: Required software functions are unavailable; related commands may fail or trigger syntax errors

Quick Fix for KUKA KSS01005 Software Option Missing

If KUKA KSS01005 appears, check the following first:

• Verify the required software option is installed
• Check license status in KUKA License Manager
• Confirm the WorkVisual project matches installed tech packages
• Review recent updates, restores, or deployments
• Reinstall missing software packages if needed
• Restart the controller after changes

👉 In most cases, this error is caused by missing tech packages or license issues, not hardware faults.

What KUKA KSS01005 Actually Means

KSS01005 indicates that the controller is trying to use a software option or technology package that is not installed, not activated, or not recognized.

Common KUKA software options include:

• SafeOperation
• ConveyorTech
• ForceTorqueControl
• RSI (Robot Sensor Interface)
• EthernetKRL
• Other motion or process-specific packages

If a program, project, or configuration references one of these—but the controller cannot find it—the error is triggered.

In short:
The robot is calling a feature that does not exist on the controller.

Typical Symptoms on Site

• KRL commands fail to compile
• Programs stop when calling specific functions
• SmartHMI displays “Software option missing”
• Certain menus or features are unavailable

Common Causes of KUKA KSS01005

1. Missing Tech Package Installation

The most common cause is that the required software package was never installed.

• Program uses ConveyorTech but it is not installed
• Project references SafeOperation without installation
• EthernetKRL commands used without the package present

2. License Not Activated or Expired

Some KUKA options require valid licensing.

• Missing license
• Expired license
• Invalid or corrupted license file
• License not properly imported

3. WorkVisual Project Mismatch

A deployed project may reference software modules not installed on the robot.

• Projects copied between robots
• Restored backups from different configurations
• Offline projects deployed without validation

4. KSS Version Incompatibility

After upgrading KSS:

• Older tech packages may become incompatible
• Unsupported versions may fail to load

This can trigger KSS01005 even if the package appears installed.

5. Corrupted Installation or Restore Failure

Improper shutdowns or failed updates may damage:

• Package registration files
• Option configuration files
• Installation directories

How to Troubleshoot KUKA KSS01005

Step 1 – Identify the Missing Option

• Check SmartHMI or log messages
• Identify which function or package triggered the error

Step 2 – Check Installed Tech Packages

• Review installed options in SmartHMI or WorkVisual
• Confirm all required packages are present and active

Step 3 – Verify License Status

• Check KUKA License Manager
• Ensure licenses are valid and correctly installed

Step 4 – Compare WorkVisual Project

• Run Online vs Offline Compare
• Verify project requirements match controller configuration

Step 5 – Reinstall Missing Package

• Install from original media
• Import license if required
• Restart controller

Recommended Tools

👉 Hardware replacement is rarely required unless storage failure causes software corruption.

Pro Diagnostic Tip

Before deploying any project in WorkVisual, always run:

Compare → Online vs Offline

This quickly reveals:

• Missing tech packages
• Unsupported options
• Version mismatches

Most KSS01005 issues are caused by deploying incompatible projects.

How to Fix KUKA KSS01005

• Install the required software package
• Activate or renew the license
• Remove unsupported commands if the option is not required
• Align WorkVisual project with controller configuration
• Reinstall corrupted modules if necessary

How to Prevent KUKA KSS01005

• Maintain backups before updates
• Track installed licenses and package versions
• Verify compatibility before KSS upgrades
• Always compare projects before deployment
• Document software requirements for each robot

Recommended Maintenance Plan

• Before deployment: Run project comparison
• After updates: Verify option availability
• Regularly: Check license validity

Related Errors

• KSS01006 License Error – Option present but not authorized
• KSS01007 Version Incompatibility – Software version mismatch
• KSS01001 Configuration Data Error – Invalid system configuration
• KSS01002 System Variable Fault – Missing variables from unloaded packages

👉 These errors are typically related to software configuration issues or missing modules.

FAQ About KUKA KSS01005

What causes the KSS01005 Software Option Missing error?

This error is caused by missing or unlicensed software modules, usually due to installation issues, license problems, or configuration mismatches.

How do I activate the missing software option?

Use KUKA License Manager to verify and import the correct license, then reinstall the required software package if needed.

Can the robot run without the missing option?

Yes, but affected functions will be disabled or limited. Some programs may not run at all.

How can I prevent this error?

Regularly verify software installation, maintain valid licenses, and ensure project compatibility before deployment.
